Kenwood KAC-PS702EX

Kenwood KAC-PS702EX amplificatore a due canali stereo/mono Serie Performance Standard, la linea top degli amplificatori Kenwood, fornisce dinamiche eccezionali tenendo una riproduzione musicale di alto livello

Caratteristiche tecniche del KAC-PS702EX

Performance Standard Serie

Stereo or mono setup

500W Maximum output power

Built-in Low-pass filter

Signal Sensing Turn-on

Speaker level input

Power MOS-FET switching power supply

Die cast aluminium heat sink

Load Capability 2Ω Stable

Maximum power output 500W

Rated power output (4Ω) 70W x 2 (4Ω)

Rated power output 60W x 4 (4Ω)

Bridged power output (4Ω) 170W x 1

CEA-2006 Compliant

Low-pass Filter

Switched Mode Power supply, MOS-FET

Signal Sensing Turn-on

Line in 2 RCA's

Speaker level Input

Single Side Terminals

Die-Cast Aluminium Heat Sink

Amplifier-Specifications

Rated power output (4Ω, 14,4V) 70W x 2 (20Hz ~ 20000Hz, 1%THD)

Rated power output (2Ω, 14,4V) 85W x 2 (1000Hz, 1%THD)

Rated power output (CEA-2006) 70Watts RMS x 2 at 4 ohms and 1% THD

Low-pass Filter 80Hz (-18dB/oct)

RCA Input Sensitivity 0.2 ~ 5V

Speaker Level Input Sensitivity 4 ~ 12V

Input Impedance 10k?

Signal to Noise Ratio 100dB

Signal to noise ratio (CEA-2006) 80dBa (Reference: 1 Watt into 4 Ohms)

Frequency response (+0dB, -3dB) 20Hz ~ 50Hz

Operating voltage 14.4V (11V ? 16V allowable)

Maximum current consumption 15A

Dimensions (WxHxD) 230 x 56 x 167(mm),

Weight 1.4kg
