Audiocontrol HPX - occasione -

Audiocontrol HPX usato su auto demo, perfettamente funzionante, foto reali del prodotto.
Processore di segnale analogico con crossover e pre integrati.

• High Definition Expansion (HDE)
• 24 dB/Octave Linkwitz Riley crossover
• Pre-amp gain of 20 dB
• Line driver: 13 volts peak output
• Balanced differential inputs
• Subwoofer level control
• Signal-sensing display
• High headroom PWM switching power supply
• Switchable backlighting (amber/green)
• Master volume and fader control
• Selectable ground isolation
• Optimum-voltage LED
• Speaker-level inputs
• Stereo 1¤8" jack input



Specifiche tecniche:
Maximum input/output level . . . . . . . .. . . . . . . . 9.5 Vrms/13 V peak
Frequency response . . . . . . . . . . . . . . . . . . . 20 Hz-100k Hz; ±1 dB
Total harmonic distortion . . . . . . . . . . . . . . . . . . . . . . . . . . .0.005%
Signal to Noise ratio . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . -110 dB
Input Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20K ohms
Output Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 ohms
Input gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0- 20 dB
Crossover slope . . . . . . . . . . . . . . . . . 24 dB/octave Linkwitz Riley
Factory crossover setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 90Hz
Power supply . . . . . . . . . . . . . . . . High headroom PWM switching
Power draw . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . 250 mA
Recommended fuse rating . . . . . . .  . . . . . . . . . . . . . . . . . 1 Amp
Illumination Color . . . . . . . . . . . . . . . . .  switchable green or amber
Size . . . . . . . . . . . . . . . . . . . . . . .. . . . . .  1" H x 6.75" W x 5" D
Weight . . . . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . .  2 lbs
