Kenwood CAW-ANT450 Antenne sintonizzatore Digitale Terrestre

il tuo prezzo: € 68,00

Prezzo riferito a singolo pezzo (IVA inclusa)

Coppia di antenne per sintonizzatore TV Digitale Terrestre Kenwood KTC-D600E.


Caratteristiche Principali CAW-ANT450

Active antenna
Broadband reception in VHF and UHF
Small mechanical dimensions
Direct connection to the receiver
Attractive design
High effective passive signal collection for high C/N ratio
Low noise integrated amplifier
Optimized internal gain
Low-pass filtering for suppression of GSM, DECT, and other carriers > 862MHz
High-pass filtering for suppression of impulsive noise, public broadcasting < 174MHz



Active antenna Si
Antenna principle Dual 1/4λ plated CF-dipole
Amplifier principle Low noise single stage amplifier
Connection Fixed flexible cable 5m with F-connector
Indicatore potenza Si, Yellow LED
Number of antenna in box

2 piece(s)



Impedenza uscita 75 Ohm
Integrated filtering (Bandpass) 174MHz ~ 240MHz & 470MHz ~ 862MHz
Gamma di frequenze 174MHz ~ 240MHz & 470MHz ~ 862MHz
Channels (CCIR) 5MHz ~ 12MHz & 21MHz ~ 69MHz
Internal amplifier gain 17 dBi typ.
Antenna gain (UHF) 10 ~ 12 dBi typ.
Radiation pattern Slightly directive
Directivity (front/back) 3dB


Specifiche Tecniche

Tensione di funzionamento 5V (4,5 ~ 5,5V Allowable)
Consumo 0,025A
Dimensioni (LxAxP) 144 x 28 x 6,5mm
Peso 73gr
