SX 165 Neo 165mm SPL coaxial speakers for car, motorcycle and outdoor

Hertz
Your price:
€ 199,00
Price per pair (VAT included)
Available on backorder
Calculating shipping costs to
Type
Coaxial
Speaker Size
165 mm
Coaxial Type
2-way
Frequency Response
100 - 20.000 Hertz
MAX Power
200 Watt
RMS Power
100 Watt
Sensitivity
96,5 dB
Impedance
4 Ohm
Woofer Material
Cellulosa pressata
Tweeter Material
PEI

Hertz SX 165 NEO 165mm Coaxial SPL Water-Resistant, Moisture-Resistant and UV-Resistant

165mm SPL coaxial speakers with cone made of high-rigidity pressed paper, resistant to atmospheric agents, with innovative water-resistant, moisture-resistant and UV-resistant treatments. Speakers suitable for cars, motorcycles, powersports applications and outdoor use.

The double-layer copper voice coil is wound on a polyamide former and guarantees unprecedented power handling. The new motor assemblies are made of special Neodymium N38 H to achieve minimal size and higher performance. SX 165 NEO is equipped with a large 1.4" PEI dome tweeter with solid-state resettable protection circuit and a protective rubber gasket for high SPL and safe outdoor use.

Features SX 165 NEO

  • High-rigidity pressed paper cone, weatherproof, with innovative water-repellent and UV-resistant treatments.
  • Extreme SPL performance lasting in compact sizes and lightness thanks to N38 H neodymium magnet.
  • Unprecedented power handling provided by the double-layer copper voice coil, wound on a polyamide former.
  • 1.4" Hi-SPL PEI dome tweeter with neodymium magnet and resettable solid-state tweeter protection circuit.
  • Dual faston terminals allow connection of multiple units and guarantee compatibility with the most common motorcycle connections.

Scheda tecnica

n-20210427121858-hertz-sx-165-spl-neo-tech-sheet.pdf

Hertz SX 165 NEO Technical Specifications

  • SPL Midrange Component
  • Dimensions mm (in.) 200 (8)
  • Power Handling
    • Continuous W 200
    • Peak W 500
  • Impedance Ohm 4
  • Voice Coil Ø 38.6 (1.5)
  • Frequency Response Hz 100 ÷ 8k
  • Magnet Dimensions D x d x h mm (in.) 80 x 50 x 6 (3.15 x 1.97 x 0.24)
  • Speaker Weight kg (lb.) 1.2 (2.65)
  • Magnet Neodymium
  • Cone Water-repellent Pressed Paper
  • D mm 168
  • Re Ohm 3.2
  • Fs Hz 103
  • Le mH 0.06
  • Vas I 8.1
  • Mms g 19.9
  • Cms mm/N 0.12
  • BL T*m 8.8
  • Qts 0.52
  • Qes 0.55
  • Qms 7.4
  • Spl dB 100
€ 199,00 Price incl. VAT
