SR 165S 2-way system 165 mm woofer - 20 mm tweeter - 90dB - 2?

BLAM
Your price:
€ 199,00
Price per single item (VAT included)
Available on backorder
Calculating shipping costs to
Type
2-way separate kit
Frequency Response
60 Hz - 8 KHz Hertz
Woofer Size
165 mm
MAX Power
150 Watt
RMS Power
75 Watt
Sensitivity
94 dB
Impedance
3 Ohm

BLAM SR 165S 2-way system 165 mm woofer - Tw 20 mm. - 90dB - 2Ω


This two-way system is designed to offer exceptional audio quality, meeting the expectations even of the most demanding audiophile. With a maximum power of 150 W and a rated power of 75 W, frequency response from 60 Hz to 25 kHz, impedance of 3 Ω and sensitivity of 93 dB, it guarantees rich and detailed acoustic performance. The kit includes 165 mm woofers equipped with a basket reinforced with fiberglass composite, a cellulose pulp membrane treated for faithful sound reproduction and a butyl perimeter suspension for optimal durability.

These components are completed by a long-lasting "Conex" spider, a 25 mm voice coil on Kapton support and an 85 x 17 mm magnetic motor with a 5 mm magnetic circuit for increased efficiency. The 20 mm tweeters, with their high-quality soft dome and N38 neodymium motor, incorporate 6 dB/octave high-pass filters and allow you to adjust their sound level to 0 dB or -3 dB based on your preferences. The kit also includes two crossovers, mounting screws, tweeter mounting accessories, an angled bracket and instruction manual, ensuring simple installation and high-level performance.

Scheda tecnica

n-20250408104941-sr-165f.pdf

BLAM SR 165S Technical Specifications

  • Maximum power 150 W
  • Rated power 75 W
  • Impedance 3 Ω
  • Frequency response 60 Hz - 8 KHz
  • Sensitivity (2.83V/1m) 94 dB
  • Magnet Ferrite
  • Magnet dimensions Ø x h 85 x 17 mm
  • Total driver displacement 0.11 l
  • Weight of one component 1.04 kg
  • Voice coil Ø 25 mm
  • Voice coil height 12 mm
  • Cone Treated cellulose pulp
