PW 8 20cm subwoofer, 300 Watt RMS power

ETON
Your price:
€ 110,40
instead of:€ 115,00
You save € 4,60
Offer valid until 29/11/2026
Price per single item (VAT included)
Black Friday: offers valid until 29 November
Calculating shipping costs to
Type
Subwoofer
Speaker Size
200 mm
MAX Power
400 Watt
RMS Power
300 Watt
Sensitivity
81 dB
Impedance
2 + 2 Ohm
Weight
4,6 Kg
Installation Depth
131 mm
Woofer Material
Cellulosa trattata

ETON PW8 subwoofer 200 mm (8 inch) with dust-painted metal basket and dual 50 mm aluminum voice coil.

Pressed and stiffened paper cone and long-excursion surround, impedance 2 x 2 Ohm, power handling 300/400 Watt. Designed for optimal ventilation, powerful ferrite magnet with silicone coating/protection, external diameter 216, installation depth 131 mm, sound pressure level 81.5 dB, weight 4.6 kg.

Manuale utente

n-20230203101346-pw8-pw10-pw12-single-chassis-20201020.pdf

Technical specifications of the ETON PW8 subwoofer

Nominal impedance (Ohm) 2 x 2 Ohm
DC resistance Re 3.8 Ohm
Resonance frequency fs 1W / TSP (Hz) 37.0
Q QTS 0.514
Q QES 0.564
Q QMS 5.843
Equivalent air volume of suspension VAS (dm3) 8.998
Force factor BL x l (Tm) 13.560
Suspension compliance CMS (mm/N) 0.175
Total moving mass MMS (g) 105
Voice coil diameter 50 mm
Mobile voice coil inductance Le (mH) @ 10 kHz 1.640
Effective piston surface SD (cm2) 190
SPL (dB) *at 1 W / 1 m 81.0
Nominal power / music power (W) 300/400 W
