PNW-XN3 3-way passive crossover network

Audiocontrol
Your price:
€ 170,10
Price per single item (VAT included)
Available on backorder
Calculating shipping costs to

Audiocontrol PNW-XN3 3-Way Passive Crossover Network designed to transform an existing 2-way component speaker system into a complete 3-way installation

The PNW-XN3 is a 3-way passive crossover network designed to expand an existing 2-way component speaker system into a complete 3-way configuration, adding a dedicated midrange driver to the midbass and tweeter combination. It is an ideal solution when active crossovers or a DSP are not available or when these are not within budget.

Compatible with both the PNW series speakers and the Altitude series from AudioControl, the PNW-XN3 simplifies system design and installation by combining all crossover functions in a single network. This eliminates the need for separate crossovers for each individual driver, reducing wiring complexity and saving precious time during installation. Only one PNW-XN3 is needed for each complete 3-way front system, capable of supporting a total of six speakers.

When it receives a full-range signal, the PNW-XN3 accurately divides the frequencies and routes them to the appropriate drivers:

  • Mid-bass frequencies to 6.5 inch or 6×9 inch woofers (WF outputs)
  • Midrange frequencies to 2.75 inch or 3.5 inch midrange speakers (MD outputs)
  • High frequencies to tweeters (TW outputs)

The flexible input section allows the PNW-XN3 to provide six output channels regardless of whether it is powered by 2, 4 or 6 input channels. As it is a completely passive crossover network, it does not require power connections, grounding or turn-on, further simplifying installation and improving reliability.

€ 170,10 Price incl. VAT
