GL2 Pair of 50 mm midrange drivers

Brax
Your price:
€ 589,00
Price per pair (VAT included)
Available on backorder
Calculating shipping costs to
Type
Midrange
Speaker Size
50 mm
MAX Power
120 Watt
RMS Power
80 Watt
Frequency Response
400 - 20000 Hertz
Sensitivity
84 dB
Impedance
4 Ohm
Installation Depth
27 mm
Midrange Cone Material
Alluminio

BRAX GL2 Pair of 50 mm midrange drivers

Every single component, from the basket to the diaphragm, has been designed and manufactured to achieve optimal results. The GL2 can be used without an additional tweeter thus reaching a new level of spatial music reproduction in the car. The extremely rigid aluminum cone provides a particularly natural response to midrange with particularly dynamic sound characteristics while the neodymium magnet system contributes to an exceptionally low distortion factor.

BRAX GL2 Technical Specifications

  • RMS / max. Power P 80 / 120 Watt (high-pass > 400 Hz at 24 dB/Oct.)
  • Impedance Z 4 Ω
  • DC resistance Re 3.1 Ω
  • Frequency response 400 Hz - 20,000 Hz
  • Resonance frequency Fs 165 Hz
  • Mechanical Q factor Qms 8.90
  • Electrical Q factor Qes 0.55
  • Total Q factor Qts 0.52
  • Compliance Cms 720 μm/N
  • Equivalent air volume Vas 0.24 L
  • Force factor B*I 2.6 Tm
  • Efficiency 1 W / 1 m SPL 84 dB
  • Cone area Sd 15 cm²
  • Moving mass Mms 1.6 g
  • Cone material Aluminum cone
  • Mechanical resistance Rms 0.13 kg/s
  • Voice coil diameter ø 19 mm/0.75
  • Voice coil winding height 5 mm/0.2
  • Maximum linear excursion Xmax +/- 1.0 mm
  • Outer diameter ø 60 mm/2.36"
  • Installation diameter ø 53 mm/2.1"
  • Installation depth 26.8 mm / 1.1"
Recommended enclosure volumes
Sealed box with minimum net volume of 250 ml

Net volumes Recommended DSP/amplifier settings
  • 0.25 liters (system resonance: 200 Hz) - Crossover frequency: 600 Hz Filter slope min: 12 dB/Oct.
  • 0.5 liters (system resonance: 155 Hz) - Crossover frequency: 450 Hz Minimum filter slope: 12 dB/Oct.
  • 0.75 liters (system resonance: 140 Hz) - Crossover frequency: 300 Hz Minimum filter slope: 24 dB/Oct.
€ 589,00 Price incl. VAT
