CB-Z321 D1.5 dual 1.5 ohm voice coil

DD Audio Digital Designs

Discontinued

Your price:
€ 3490,00
Price per single item (VAT included)
Type
Subwoofer
Speaker Size
Other sizes
MAX Power
8.000 Watt
RMS Power
1.000 - 4.000 Watt
Impedance
1.5 + 1.5 Ohm
Weight
34,5 Kg
Installation Depth
335 mm

Audio Digital Design CB-Z321 subwoofer 50cm with dual 1.5 Ohm voice coil, maximum power 8,000 W, cone in carbon fiber and uncompressed cellulose, glossy dust cap with red DDA Z logo.

The current Z3 generation is an open motor design at neodymium 13 lens grade 52. The motivation behind the Z series is to build the best high power handling driver of all time and considering the Z mission accomplished, at DD they identified the key design elements that presented opportunities for improvement: the results are the latest versions of the Z3 drivers.

The steel engine parts are machined in their United States facilities with the best materials and production methods available.

Current Z models feature numerous design improvements over previous models: increased peak and total flux levels, allowing more energy to flow through the magnetic lens design and more efficient flux paths, closer alignment of the lenses and converging flux lines.

The free-flowing cooling system was improved by incorporating longitudinal ventilation openings to increase air flow to the battery. Then the thermal mass was increased and heat-absorbing coatings were used in target areas to aid in long-term heat dissipation.

The geometric modifications that allowed increasing the maximum excursion capacity and a broader range of system design configurations.

Audio Digital Design CB-Z321 technical specifications

Diameter 530 mm

Voice coil diameter 85 mm

RMS Power 1,000 - 4,000 W

Maximum power 8,000 W

Impedance 1.5+1.5 Ohm

Installation hole diameter 489 mm

Installation depth 335 mm

Weight 34.5 Kg

Discontinued
