CB K130.2-S3 Compose Basic - 130 mm 2-way speaker kit

Helix
Your price:
€ 187,00
Price per pack (VAT included)
Available on backorder
Calculating shipping costs to
Type
2-way separate kit
Frequency Response
80 - 22.000 Hertz
Woofer Size
70 mm
Tweeter Size
20 millimetri
MAX Power
105 Watt
RMS Power
70 Watt
Sensitivity
90 dB
Impedance
3 Ohm
Woofer Material
Polipropilene
Tweeter Material
Cupola in seta

HELIX CB K130.2-S3 Compose Basic - 130 mm 2-way speaker kit

Transform your musical experience in your car with the Helix CB K130.2-S3 Kit, the speaker that brings sonic perfection to every composition. This kit represents the pinnacle of evolution in universal speaker systems. With innovative materials, advanced technologies and intelligent engineering, the kit offers high efficiency, exceptional sound quality and surprising dynamics, all perfectly adapted to your vehicle. HELIX COMPOSE is the future of car audio.
The BASIC component system is your gateway to the world of HELIX COMPOSE. Each component is studied for perfect harmony and combines with HELIX and MATCH amplifiers to guarantee maximum performance. The BASIC tweeter integrates intelligent mechanical technologies, guaranteeing secure connection and professional installation. HELIX COMPOSE is synonymous with intelligent technology, with extraordinary efficiency thanks to 3 Ohm technology. This technology integrates perfectly with HELIX and MATCH amplifiers, offering a tangible advantage in terms of efficiency and sound pressure. Some models are also available in optional 2 Ohm variants, guaranteeing optimal performance in combination with the suitable amplifier.
The COMPOSE woofer-midrange of the BASIC series combines high efficiency with exceptional sound quality. The lightweight yet durable polypropylene diaphragm delivers extraordinary performance, while the robust basket is designed with ventilation holes for optimal cooling. Powerful magnets guarantee ideal impulse response, while the soft polyurethane surround optimizes frequency response. The compact design fits perfectly into tight spaces. In the sonic world of HELIX COMPOSE, precise highs are essential. The BASIC tweeter uses a silk-coated dome and a high-efficiency neodymium magnet for crystalline reproduction and unique dynamics in the high frequencies.
The crossover offers 4-stage tweeter level adjustment with a 12 dB slope for optimal adaptation to the installation. Integrated tweeter protection ensures safety and reliability. The crossover offers optimal frequency distribution, ensuring a harmonious sound image and an engaging experience.
FlexMount20 is the adapter ring that makes it possible to install FlexMount COMPOSE speakers in a wide range of vehicles. The universal tweeter thus becomes a specific component for your vehicle, guaranteeing optimized installation and superb acoustic experience.
Compatibility
  • FlexMount20
CB K130.2-S3 Features
  • 2-way speaker kit that combines high efficiency and exceptional sound performance
  • 3 Ohm technology to maximize amplifier power
  • Compact design for problem-free installation even in tight spaces
  • 0.75" / 20 mm tweeter with silk dome for bright and clear high response
  • Very efficient neodymium magnet for high magnetic flux linearity
  • Compact design and various mounting options to meet numerous installation needs
  • Mounting brackets for flush and angled mounting are included in the package
  • Designed for FlexMount20 adapters, available as optional, which allow acoustically optimized and professional integration in the original mounting locations of the vehicle.
  • 5.25" / 130 mm midbass with lightweight polypropylene cone that provides essential rigidity for exceptional sound performance.
  • Robust steel basket with additional ventilation holes for better voice coil cooling and high power handling
  • Powerful magnet system for optimal impulse control
  • Polyurethane surround for optimized frequency response in the upper midrange area
  • Separate high-quality crossover with compact dimensions for easy integration
  • 4-stage tweeter level adjustment with integrated tweeter protection for optimal adaptation of highs to the mounting position
  • Extended fine tuning - with 12 dB slope for the tweeter

Manuale d'uso

n-20230831094909-manuale-cb-k130-2-s3.pdf

2 Tweeter CB T20FM-S 2 Midbass CB W130-S3 2 Crossover CB FX130.2 2 Tweeter mounting accessory Mounting material

HELIX CB K130.2-S3 Technical Specifications

  • Power handling RMS / Max. P 70 / 105 Watt
  • Frequency response 80 Hz - 22,000 Hz
  • Impedance Z 3 Ω
  • Sensitivity SPL
    • 90 dB @ 2.83V / 1m
    • 86 dB at 1W / 1m
  • Outer diameter ø
    • Tweeter: 32.0 mm / 1.26"
    • Midbass: 130 mm / 5.12
  • Installation diameter ø
    • Tweeter: 32.0 mm / 1.26"
    • Midbass: 118.0 mm
  • Installation depth
    • Tweeter: 9.8 mm
    • Midbass: 51.4 mm
  • Crossover dimensions
    • 103.3 x 50.4 x 25.0 mm/4.07 x 1.98 x 0.98"

Midbass

  • Impedance Z 3 Ω
  • DC resistance Re 3.0 Ω
  • Resonance frequency Fs 88 Hz
  • Mechanical Q factor Qms 4.10
  • Electrical Q factor Qes 1.12
  • Total Q factor Qts 0.88
  • Compliance Cms 320 μm/N
  • Equivalent air volume Vas 4.2 L
  • Force factor B*l 3.9 Tm
  • Cone area Sd 97 cm2
  • Moving mass Mms 10.1 g
  • Mechanical resistance Rms 1.30 kg/s
  • Voice coil diameter ø 25 mm
  • Voice coil winding height 8.9 mm
  • Maximum linear excursion Xmax +/- 2.5 mm


Tweeter

  • Impedance Z 4 Ω
  • Resonance frequency Fs 2000 Hz
  • Voice coil diameter ø 20 mm
