165 S80 2-way 165 mm system with passive crossover

BLAM
Your price:
€ 569,00
Price per single item (VAT included)
Available on backorder
Calculating shipping costs to
Type
2-way separate kit
Frequency Response
60 Hz – 7 KHz Hertz
Woofer Size
165 mm
MAX Power
120 Watt
RMS Power
60 Watt
Impedance
2 Ohm

BLAM 165 S80 2-way system 165 mm with passive crossover


The KIT 165 S80 is a 2-way audio system designed to provide precise and powerful sound reproduction in your vehicle. It consists of two 165 mm S 6.80 woofers, equipped with an ultra-rigid carbon fiber cone and a 28 mm voice coil on a fiberglass support, delivering a maximum power of 120 W with a frequency response from 60 Hz to 7 KHz.

This kit also includes two 20 mm T20HR tweeters with textile dome and high efficiency neodymium magnet, which guarantee clear and detailed highs. Finally, the BFT01 - BFW01 filters ensure optimal sound management thanks to a 6 dB/octave high-pass filter and tweeter level adjustment at 0 dB or attenuated to -3 dB. The whole forms a high-performance audio system, ideal for an immersive and dynamic driving experience.

BLAM 165 S80 Technical specifications

Woofer S 6.80

  • Maximum power 120 W
  • Nominal power 60 W
  • Frequency response 60 Hz - 7 KHz
  • Impedance 2 Ohm
  • Die-cast aluminum basket
  • Ultra rigid carbon fiber cone
  • Sound IIR
  • "Conex" long-lasting spider
  • 28 mm voice coil, fiberglass support
  • 80 mm x 17 mm magnetic motor
  • Worked pole extensions
  • Gold-plated terminals

Tweeter T20HR

  • 5 Ω
  • Neodymium magnet
  • 20 mm (3/4″) textile dome diaphragm
  • High efficiency magnet (neodymium N38H)
  • Ferrofluuid for high power handling

Filter BFT01 - BFW01

  • High-pass filter 6 dB/octave
  • Tweeter level adjustable at 0 dB or attenuated to -3 dB
€ 569,00 Price incl. VAT
