110 10" S4 Subwoofer

DD Audio Digital Designs

Discontinued

Your price:
€ 89,10
Price per single item (VAT included)
Type
Subwoofer
Speaker Size
250 mm
MAX Power
600 Watt
RMS Power
100 Watt
Sensitivity
90 dB
Impedance
4 Ohm
Installation Depth
123 mm
Woofer Material
Cellulosa trattata

DD Audio Digital design DD110 subwoofer 10" S4

The DD110 has been designed to have high output with a minimum of 100 Watts. Hand built and tuned to perform well in sealed and ported enclosures.

DD110 Features

  • Dual layer EROM surround
  • High temperature resistant aluminum 2.0" voice coil
  • Dual layer laminated spider
  • Unpressed paper cone
  • Basket with cooling vent

DD Audio Digital design DD110 technical specifications

  • 10" / 25 cm Subwoofer
  • RMS Power 100 W
  • Maximum Power 600
  • Voice coil diameter 2" / 5 cm
  • Impedance 4 Ohm
  • Piston diameter - in 8.5
  • Fs - Hz 40
  • Qms 5.965
  • Qes 0.6312
  • Qts 0.5708
  • Vas - liters 60.36
  • dBSPL 90
  • Frame outside diameter 257.5 mm
  • Mounting diameter 230 mm
  • Mounting depth: 123 mm
  • Motor diameter: 138 mm

Recommended box volumes:

  • Sealed enclosure - cu ft 0.75-1.25
  • Ported enclosure - cu ft 1.25-1.50
Discontinued
